Desktop Pick and Place Machine

Assemble your Prototype PCB’s easily and accurately, with a PlacerBot.

Automate your development

Our Ecosystem

PlacerBot This desktop pick and place machine gives the capability to perform precise placement and reliable and repeatable assembly of printed circuit boards. This affordable machine is geared for the prototyping needs of startups, education



PlacerBot Reflow Oven The desktop sized reflow oven. The reflow oven follows precise profiles to evenly solder the printed circuit board. The reflow oven handles all paste types and can solder lead-free paste.

PlacerBot-Trainer The simulator designed for multi-user environments like educational institutes and shared space to optimize the time spent on the PlacerBot. This software enables the user to setup the project for the desktop pick and place machine in an offline manner. This saves time spend during setup of the system

PlacerBot-Paste This solder paste dispensing system enables the automatic application of the solder paste on the printed circuit board. (coming soon)




PlacerBot

  • Optimized for prototyping

  • Handles 0201 to fine pitch ICs

  • Flexible feed volume

  • Automatic Tool Changer

  • Fits on your desktop

  • QR Codes for Component Identification

  • What-You-See-Is-What-You-Get

  • Fully Automatic and Semi-Automatic modes

More Information

About
PlacerBot

Desktop Pick And Place robot for automatic assembly of electronic Printed Circuit Boards (PCBs).

Optimized for prototyping and low-volume production.

Ideal for start-ups, maker labs, R&D and academia

Composition

Feeders

SMD placement

PlacerBot Features

Just some of our features

100%

GUI

Gerber Overlay
What-You-See-Is-What-You-Get placement
Placement & Inspection Aid

100%

Placement

From SMD 0201 (0.6 x 0.3 mm) to 1206
Chips 144-pin 0.5 mm pitch
Fully Automated Working

100%

Composition

Sliding feeder bay
Automatic tool changer
Automated operation from pick to place

Desktop Reflow Oven

from our eco-system

About
Desktop Reflow Oven

The desktop sized reflow oven. The reflow oven follows precise profiles to evenly solder the printed circuit board

LEARN MORE

Testimonials

Here’s what our happy customers had to say about our services:

With PlacerBot-PNP, our prototyping time & efforts have been considerably reduced while meeting the quality requirements. We see this system an essential part of Electronics Hardware R&D units where the turnaround time is crucial.

We wish Team Zoid Labs bringing greater levels of advancements in portable SMD assembly solutions in future

Jayakrishnan, HW Design Labs

Latest News

GINSEP 30Oct2020

October 30th, 2020|Comments Off on GINSEP 30Oct2020

Come and visit us today at the expo as part of GINSEP Digital Journey to

  • Visit Big Demo Day

Big Demo Day 21 Oct 2020

October 21st, 2020|Comments Off on Big Demo Day 21 Oct 2020

PlacerBot is participating in the Big Demo Day 21 Oct 2020, organized by the Kerala

Inda Electronics Week Feb 2020

February 13th, 2020|Comments Off on Inda Electronics Week Feb 2020

PlacerBot receives an overwhelming response at the India Electronics Week (IEW) 2020 held in
